Amana Tool 51499 6mm 单刃螺旋上切铣刀
产品详情
产品概述
51499, Amana Metric Solid Carbide CNC Spiral 'O' Single Flute 6 Dia x 38 x 6 Shank x 75mm Long Up-Cut Router Bit
本产品**用于带有自动进给功能的 CNC 机床和雕刻机。能够产生超洁净、平滑的切口，尤其适用于亚克力材料（Plexiglas® Lucite®）、其他塑料和木材。刀具采用**硬质合金等级制造，符合严格公差，并通过 Amana 独特工艺抛光至镜面 finish。设计用于向上排屑，非常适合工业应用和 CNC 机床。右旋右切。
适用材料
Excellent for cutting:
- 塑料/亚克力
- 缩醛和尼龙
- 亚克力石
- 丙烯腈丁二烯苯乙烯 (ABS)
- 铝复合材料 (ACM)
- Alupanel®
- Corian
- Coroplast®**
- 波纹塑料* 如 Correx 板和聚丙烯
- Delrin
- Dibond®
- 挤出亚克力
- 泡沫板
- Gatorfoam®***
- 硬塑料
- 高密度聚乙烯 (HDPE)
- 高密度聚氨酯 (HDU Board)
- 高抗冲聚苯乙烯 (HIPS)
- 用于数码打印的高抗冲聚苯乙烯 (HIPS)
- King ColorCore® 多色可雕刻聚合物片材
- 层压板
- 低密度聚乙烯 (LDPE)
- Lucite®
- 机械/工程塑料
- Perspex® 浇铸亚克力片材
- Plexiglas®
- 聚甲基丙烯酸甲酯 (PMMA)
- 聚碳酸酯 (Lexan™)†
- 改性聚对苯二甲酸乙二醇酯 (PETG / PET-G)
- 聚苯乙烯 (PS)
- PVC
- Sintra PVC
- 实心表面材料
- Teflon®
- 热塑性聚烯烃 (TPO)
- 超高分子量聚乙烯 (UHMWPE)
- 木材
规格参数
| Direction | Up-Cut (上切) |
|---|---|
| (D) Diameter | 6mm |
| (B) Cutting Height | 38mm |
| (d) Shank | 6mm |
| Overall Length (L) | 75mm |
| Flutes | 1 |
*Corrugated Plastics such as Correx refers to a wide range of extruded twinwall plastic-sheet products produced from high-impact Polypropylene resin with a similar make-up to corrugated fiberboard. They are used in a variety of applications including boat building packaging signage outdoor advertising and the production of pet cages.
**A soft plastic cardboard made with super soft super flexible PVC.
***Gatorfoam® Foam Board a polystyrene foam board bonded between two layers of Luxcell® wood-fiber veneer.
†Recommendation: Use the slowest suggested feed rates and the shortest bits necessary for cutting and routing Lexan™.
镜面抛光优势
- razor sharp cutting edge ( razor sharp 切削刃)
- Effortless chip removal (轻松排屑)
- Helps prevent chip re-welding (有助于防止切屑重焊)
- Extends tool life (延长刀具寿命)
- Exceptional cut quality (**的切割质量)
- Dissipates heat well and prevents melting (良好的散热性并防止熔化)
Maximum RPM: 35,000
